* Pin-to-Pin with PCIE

* Dimensions: 51mm ×31mm×4.75mm

* Weight: About 10.0g

* BD/GLONASS/GPS

* Frequency Band:

LTE FDD/LTE TDD/WCDMA/TD-SCDMA/GSM/CDMA EVDO/CDMA 1x

* C2A/C2C/C2B/C3C/C3B

1.LTE FDD: B1, B3, B5,B8

2.LTE TDD: B38, B39, B40, B41

3.WCDMA: B1, B5, B8

4.TD SCDMA: B34, B39

5.GSM: B3, B8

6.CDMA EVDO/ 1x: BC0

* E1C/E2C

1.LTE FDD: B1, B3, B7, B8, B20

2.WCDMA: B1, B8

3.GSM: B3, B8

* J2A/J2AS

1.LTE FDD: B1, B3, B5, B7, B8, B18, B19, B21

2.WCDMA: B1, B5, B6, B8, B19

* F1A

1. LTE TDD: B45/61:1.4GHz B59/62:1.8GHz

* A1C

1. GSM:B2, B3, B5, B8

2. UMTS:B1, B2, B5, B8

3. LTE FDD:B1, B2, B3, B5, B7, B8, B28

4. LTE TDD:B40

* Note: OpenLinux solution are embedded in C2A version

* Transmit Power:

LTE: 23 ±2.7dBm (Power Class 3) WCDMA : 24 +1/-3dBm (Power Class 3) TD-SCDMA : 24 +1/-3dBm GSM900 : 33±2dBm (Power Class 4) GSM1800: 30±2dBm (Power Class 1) CDMA:24 ±1dBm @ All up bits

* Receiving sensitivity::

Rx Diversity

* Power Supply:

3.0V --4.0V(3.3V /3.8V is recommended)

* Operation temperature: -30°C to +75°C

Extreme Operating temperature: -40°C to +85°C

* Storage temperature: -40°C to +85°C

* -40℃ to +85℃

* LTE FDD:

Uplink 50Mbps / Downlink 150 Mbps

* TD-LTE:

Uplink30Mbps / Downlink 112Mbps

* WCDMA:

Uplink 5.76Mbps / Downlink 42Mbps

* TD-SCDMA:

Uplink 2.2Mbps / Downlink 2.8Mbps

* EDGE (Multi-slot Class 12):

Uplink236.8 kbps/Downlink: 236.8 kbps

* GPRS (Multi-slot Class 10):

Uplink85.6 kbps/Downlink85.6 kbps

* CDMA2000 EVDO:

Uplink 1.8Mbps / Downlink 3.1Mbps

* CDMA2000 1X:

Uplink 153.6 kbps / Downlink 153.6 kbps

* Support Text and PDU mode

* Point to point MO and MT

* SMS Status Report

* SMS centre address setting

* Management of SMS

* About 3mA standby current

* USB 2.0

* UART

* SIM interface (1.8/3.0V)

* Antenna (RF PAD for Primary, Diversity and GPS)

* LED indication

* LCC 80Pi

* Reset & Power-on

* WAKE-IN & WAKE-OUT

* USB 2.0

* Support embedded TCP & UDP &FTP &HTTP protocols

* Support protocols PAP and CHAP used for PPP connection

* USB Selective Suspend & Remote wakeup

* RAS /ECM/NDIS

* Control Via AT Commands according to 3GPP TS27.005, 27.007 and ZTEWelinkextended AT commands

* Drivers:

Windows XP, Vista, 7 , 8, Win CE,Windows Mobile Linux Android

* Diag-log Tool

* Firmware update Tool
