* LCC Form Factor (80 pins)

* Pin-to-Pin with ME3630

* Dimensions: 30mm × 30mm× 2.3mm

* Frequency Band :

-LTE FDD/LTE TDD

-WCDMA*

-GSM *

* Transmit Power:

--LTE: 23 ±2.7dBm (Power Class 3)

--WCDMA: 24 +1/-3dBm (Power Class 3)

--GSM900 : 33±2dBm (Power Class 4)

--GSM1800: 30±2dBm (Power Class 1)

* Receiving sensitivity:

--Rx Diversity *

* Power Supply :

--3.4V -- 4.2V(3.8V is recommended)

* Operation temperature: -30°C to +75°C

--Extreme Operating temperature: -40°C to +85°C

* Storage temperature: -40°C to +85°C

* Humidity: 5%~ 95%

* C1A

1.LTE FDD: B1, B3, B5, B8

2.LTE TDD: B34, B38, B39, B40, B41

3.WCDMA: B1, B8

* C1B

1.LTE FDD: B1, B3, B5, B8

2.WCDMA: B1, B8

* C1C

1.LTE FDD: B1, B3, B5

* C1D

1. LTE FDD: B1, B3, B5, B8

2. LTE TDD: B34, B38, B39, B40, B41

3. WCDMA: B1, B8

* C1E

1. LTE FDD: B1, B3, B5, B8

2. LTE TDD: B34, B38, B39, B40, B41

3. WCDMA: B1, B8

4. GSM: B3, B8

* C2M

1. LTE FDD: B3, B8

2. LTE TDD: B34, B38, B39, B40, B41

3. GSM: B3, B8

* LTE FDD

-Uplink 50Mbps / Downlink 150 Mbps

* LTE FDD

--Uplink30Mbps / Downlink 112Mbps

* WCDMA

--Uplink30Mbps / Downlink 112Mbps

* EDGE (Multi-slot Class 12)

--Uplink 236.8 kbps / Downlink 236.8 kbps

* GPRS (Multi-slot Class 10)

* USB 2.0 High speed (480 Mbps)

* UART1(4-wires)

* UART2 for debug (2-wires)

* SIM interface (1.8/3.0V)

* SPI

* I2C

* Antenna (RF PAD for Primary, Diversity)

* LED indication

* Reset & Power-on

* WAKEUP-IN & WAKEUP-OUT

* Support embedded TCP & UDP protocols

* Support protocols PAP and CHAP used for PPP connection

* USB Selective Suspend & Remote wakeup

* RAS /ECM/RNDIS

* Control Via AT Commands according to 3GPP TS27.005, 27.007 and GOSUNCN extended AT commands

* Drivers

--Windows XP, Vista, 7 , 8, 10

--Linux

--Android

* Diag-log Tool

* Firmware update Tool
